LED：19*20W RGBW LED (RGBL/RGBALC/TW)

Beam Angle：10°; 25°/30°/35°/45°/60°（optional）

Ra：70 (90 is optional)

Light Source Life Expectancy：≥50,000h

Dimming：0-100% linear

CT：6000K, CCT adjustment

Color：RGBW（RGBL/RGBALC/TW) color mixing system

Ring Control

Gamma：2.0，2.2，2.4，2.6，2.8.

Refresh Rate：1K，2K，3K，4K，5K，6K，10K，15K，20K，25K.

Strobe：electronic, variable from 1-25Hz or pulse

Input Voltage：100-240V, 50-60Hz

Max. Power：400W

Input Current：1.4A

Max. Units in Series：6

Protocol：DMX512, RDM(optional)

Software Upgrade：Software Upgrade Box

Built-in program

Upgrade with DMX

Remote reset DMX address and fixture by DMX

3 control channel modes：9/11/18CH: 9/11/18 chs

Auto thermal protection circuit

Ta：- 30° - +50°C

Protection Rating：IP66

Certification compliance：CE，ROHS

Isulation Rating：CLASS I

Housing：Die-cast aluminum

Dimension(L*W*H)：293*145*310mm

Net Weight：6kg

Cooling：Convection

Mounting：Floor,wall or ceiling (adjustable bracket)

Finish：Black

Protection Rating：IP66

Cables / Connections：Power Cable + 5-pin Signal Cable

LCD Screen：Run time of fixture and light source
